🧠 CPU & Chipset

1. Socket: Intel® LGA1700
2. Supported CPUs:
3. 14th, 13th, and 12th Gen Intel® Core™
4. Intel® Pentium® Gold & Celeron®
5. Technologies:
6. Intel® Turbo Boost 2.0
7. Intel® Turbo Boost Max 3.0 (availability depends on CPU)
8. Chipset: Intel® B760

—————————————————————————————————————————————————-

🧬 BIOS & Manageability

1. BIOS: 128 Mb Flash ROM, UEFI AMI BIOS
2. Remote Features: WOL by PME, PXE

—————————————————————————————————————————————————-

🧱 Form Factor & OS

1. Form Factor: micro-ATX (24.4cm x 21.1cm / 9.6″ x 8.3″)
2. Operating System Support: Windows® 11 / Windows® 10 64-bit

—————————————————————————————————————————————————-

💾 Memory

1. Slots: 2 x DIMM, up to 64 GB
2. Type: DDR4
3. Speeds (OC):
4. 5333 / 5066 / 5000 / 4800 / 4600 / 4400 / 4266 / 4000 / 3733 / 3600 / 3466 / 3400 / 3333 / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MT/s
5. Architecture: Dual channel
6. Features: Intel® XMP, Non-ECC, Unbuffered

—————————————————————————————————————————————————-

🎮 Graphics

1. Integrated Graphics Support: Depends on CPU
2. Output: 1 x HDMI™ port

—————————————————————————————————————————————————-

🎮 Expansion Slots

1. CPU-based:
2. 1 x PCIe 4.0 x16 (for graphics cards)
3. Chipset-based:
4. 2 x PCIe 4.0 x1

—————————————————————————————————————————————————-

💽 Storage

1. M.2 Slots:
2. M.2_1 (Key M): PCIe 4.0 x4 – supports 2242/2260/2280
3. M.2_2 (Key M): PCIe 4.0 x4 – supports 2242/2260/2280
4. SATA: 4 x SATA 6Gb/s
5. RAID Support: RAID 0/1/5/10 via Intel® Rapid Storage

—————————————————————————————————————————————————-

🌐 Networking

1. LAN: 1 x Realtek 2.5Gb Ethernet

—————————————————————————————————————————————————-

🔌 USB Ports

1. Rear I/O:
2. 4 x USB 5Gbps (Type-A)
3. 4 x USB 2.0 (Type-A)
4. Front/Internal Headers:
5. 1 x USB 5Gbps header (adds 2 ports)
6. 2 x USB 2.0 headers (adds 4 ports)
7. Note: USB_E1–E4 share bandwidth

—————————————————————————————————————————————————-

🔊 Audio

1. Codec: Realtek 7.1 HD Audio
2. Features:
3. Jack detection, multi-stream, front panel retasking
4. Up to 24-bit/192kHz playback
5. Audio shielding, premium capacitors
6. Separate PCB layers for left/right channels
7. Requires HD audio chassis for full 7.1 support

—————————————————————————————————————————————————-

🧩 Internal I/O Connectors

1. Cooling:
2. 1 x 4-pin CPU fan
3. 2 x 4-pin chassis fans
4. Power:
5. 1 x 24-pin ATX
6. 1 x 8-pin +12V
7. Storage:
8. 2 x M.2
9. 4 x SATA
10. USB:
11. 1 x USB 5Gbps header (2 ports)
12. 2 x USB 2.0 headers (4 ports)
13. Miscellaneous:
14. 3 x Gen 2 ARGB headers
15. 1 x Clear CMOS
16. 1 x COM port
17. 1 x S/PDIF out
18. 1 x Front audio (F_AUDIO)
19. 1 x Speaker
20. 1 x SPI TPM
21. 1 x System panel (10-1 pin)

—————————————————————————————————————————————————-

🔙 Back Panel I/O

1. 4 x USB 5Gbps (Type-A)
2. 4 x USB 2.0 (Type-A)
3. 1 x HDMI™
4. 1 x 2.5Gb Ethernet
5. 3 x Audio jacks

—————————————————————————————————————————————————-

📦 Accessories

1. 2 x SATA cables
2. 2 x M.2 screws/anchors
3. 1 x I/O shield
4. 1 x Quick start guide

—————————————————————————————————————————————————-

⚙️ Special Features

1. ASUS 5X Protection III:
2. DIGI+ VRM, LANGuard, SafeSlot Core
3. Overvoltage Protection
4. Stainless Steel I/O Shield
5. Q-Design:
6. Q-DIMM, Q-LED Core, Q-Slot
7. Cooling:
8. ProCool connector
9. VRM heatsink
10. Lighting:
11. Aura Sync RGB (Gen 2 addressable headers)

—————————————————————————————————————————————————-

🧩 Software Suite

1. ASUS Tools: Armoury Crate, Aura Sync, Fan Xpert 2+, DIGI+ VRM
2. System Tools: PC Cleaner, ASUS CPU-Z
3. Security:
4. Norton 360 Deluxe (60-day trial)
5. WinRAR (40-day trial)
6. BIOS Tools:
7. ASUS EZ Flash 3, CrashFree BIOS 3
8. UEFI BIOS (EZ Mode + Advanced Mode)
