| CPU |
Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors / Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0 / * Refer to www.asus.com for CPU support list. / ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset |
Intel® H610 Chipset |
| BIOS |
128 Mb Flash ROM, UEFI AMI BIOS |
| Form Factor |
mATX Form Factor / 9.2 inch x 8.0 inch ( 23.4 cm x 20.3 cm ) |
| Operating System |
Windows® 11 64-bit, Windows® 10 64-bit |
| Ethernet |
1 x Realtek 1Gb Ethernet |
| Memory |
2 x DIMM, Max. 64GB, DDR4 / 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory // Dual Channel Memory Architecture // Supports Intel® Extreme Memory Profile (XMP) |
| Graphics |
1 x D-Sub port / 1 x HDMI® port // * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. // Supports 4K@60Hz as specified in HDMI 2.1. |
| Storage |
Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports // Intel® H610 Chipset : M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes) / 4 x SATA 6Gb/s ports // * The M.2 slot shares bandwidth with the SATA6G_4 port. When a device in SATA mode is installed on the M.2 slot, the SATA6G_4 port cannot be used. |
| Manageability |
WOL by PME, PXE |
| USB |
Rear USB (Total 6 ports) : 2x USB 3.2 Gen 1 ports (2 x Type-A) // 4x USB 2.0 ports (4 x Type-A) /// Front USB (Total 4 ports) : 1x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports // 1x USB 2.0 header supports additional 2 USB 2.0 ports |
| Internal I/O Connectors |
Fan and Cooling related : 1 x 4-pin CPU Fan header / 1 x 4-pin Chassis Fan header // Power related : 1 x 24-pin Main Power connector / 1 x 8-pin +12V Power connector // Storage related : 1 x M.2 slot (Key M) / 4 x SATA 6Gb/s ports // USB : 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports / 1 x USB 2.0 header supports additional 2 USB 2.0 ports // Miscellaneous : 1 x RGB header / 1 x Clear CMOS header / 1 x COM Port header / 1 x Front Panel Audio header (AAFP) / 1 x S/PDIF Out header / 1 x Speaker header / 1 x SPI TPM header (14-1pin) / 1 x 10-1 pin System Panel header |
| Expansion Slots |
Intel® Core™ Processors (14th & 13th & 12th Gen) : 1x PCIe 4.0 x16 slot // Intel® H610 Chipset : 1x PCIe 3.0 x1 slot |
| Back Panel I/O Ports |
2 x USB 3.2 Gen 1 ports (2 x Type-A) / 4 x USB 2.0 ports (4 x Type-A) / 1 x D-Sub port / 1 x HDMI® port / 1 x Realtek 1Gb Ethernet port / 3 x Audio jacks / 1 x PS/2 Keyboard/Mouse combo port |
| Audio |
Realtek 7.1 Surround Sound High Definition Audio CODEC : – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking / – Supports up to 24-Bit/192 kHz playback // Audio Features : – Audio Shielding / – Dedicated audio PCB layers // * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. |
| Special Features |
ASUS 5X PROTECTION III : – DIGI+ VRM / – LANGuard / – Overvoltage Protection / – SafeSlot Core / – Stainless-Steel Back I/O // ASUS Q-Design : – Q-DIMM / – Q-Slot // ASUS Thermal Solution : – Aluminum heatsink design // ASUS Lighting Control : – RGB header |
| Software Features |
ASUS Exclusive Software : Armoury Crate // AI Suite 3 : – Performance And Power Saving Utility // TurboV EVO // EPU // DIGI+ VRM // Fan Xpert // ASUS CPU-Z // Norton Anti-virus software (Free Trial version) // WinRAR // UEFI BIOS // ASUS EZ DIY : – ASUS CrashFree BIOS 3 / – ASUS EZ Flash 3 / – ASUS UEFI BIOS EZ Mode |
| Accessories |
Cables : 2 x SATA 6Gb/s cables // Miscellaneous : 1 x I/O Shield / 1 x M.2 ANCHOR // Installation Media : 1 x Support DVD // Documentation : 1 x User Guide |
