🧠 CPU & Chipset

1. Socket: Intel® LGA1700
2. Compatible Processors:
3. 14th, 13th, and 12th Gen Intel® Core™
4. Intel® Pentium® Gold and Celeron®
5. Intel® Technologies:
6. Turbo Boost 2.0
7. Turbo Boost Max 3.0 (depends on CPU model)
8. Chipset: Intel® Z790 High-Performance Chipset

—————————————————————————————————————————————————-

🧬 BIOS & Remote Management

1. BIOS: Dual-Bank 192Mb (128Mb + 64Mb), UEFI AMI BIOS
2. Manageability: WOL by PME, PXE

—————————————————————————————————————————————————-

🧱 Form Factor & OS

1. Form Factor: ATX (12″ x 9.2″ / 30.5 cm x 23.4 cm)
2. Operating System Support: Windows® 11 / Windows® 10 64-bit

—————————————————————————————————————————————————-

🌐 Networking

1. LAN: 1 x Realtek 2.5Gb Ethernet
2. Wireless: Intel® Wi-Fi 6 (2×2, 802.11 a/b/g/n/ac/ax), 2.4/5GHz dual-band
3. Bluetooth®: Version 5.2

—————————————————————————————————————————————————-

💾 Memory

1. DIMM Slots: 4 x DDR5
2. Capacity: Up to 192GB
3. Speeds:
4. 7200+(OC), 7000(OC), 6800(OC), 6600(OC), 6400(OC), 6200(OC), 6000(OC), 5800(OC), 5600, 5400, 5200, 5000, 4800 MT/s
5. Memory Architecture: Dual Channel
6. Intel® XMP Support: Yes (Extreme Memory Profile)
7. On-Die ECC: Supported (for DDR5, unbuffered non-ECC memory only)
8. Signal Optimization: ASUS OptiMem II

—————————————————————————————————————————————————-

🎮 Graphics

1. Integrated Graphics Support: Depends on installed CPU
2. Display Outputs:
3. 1 x DisplayPort 1.4 (4K @ 60Hz)
4. 1 x HDMI® 2.1 (4K @ 60Hz)

—————————————————————————————————————————————————-

🔌 Expansion Slots

1. CPU Lanes:
2. 1 x PCIe 5.0 x16 slot
3. Chipset Lanes (Z790):
4. 3 x PCIe 4.0 x16 (x4 mode)
5. 1 x PCIe 3.0 x1

—————————————————————————————————————————————————-

💽 Storage

1. M.2 Slots:
2. M.2_1: 2242/2260/2280/22110 (PCIe 4.0 x4)
3. M.2_2: 2242/2260/2280 (PCIe 4.0 x4)
4. M.2_3: 2242/2260/2280/22110 (PCIe 4.0 x4 & SATA)
5. SATA Ports: 4 x SATA 6Gb/s
6. RAID Support:
7. Intel® RST: PCIe RAID 0/1/5/10
8. SATA RAID 0/1/5/10

—————————————————————————————————————————————————-

🔌 USB Connectivity

1. Rear I/O (Total 8 ports):
2. 1 x USB 3.2 Gen 2×2 Type-C®
3. 1 x USB 3.2 Gen 2 Type-A
4. 2 x USB 3.2 Gen 1 Type-A
5. 4 x USB 2.0 Type-A
6. Front Panel Headers:
7. 1 x USB 3.2 Gen 2 (Type-C®)
8. 2 x USB 3.2 Gen 1 headers (4 additional ports)
9. 2 x USB 2.0 headers (4 additional ports)
10. Notes: USB_E1–E8 ports share bandwidth across pairs

—————————————————————————————————————————————————-

🔊 Audio

1. Codec: Realtek 7.1 Channel HD Audio
2. Playback Support: Up to 24-bit / 192 kHz
3. Audio Features:
4. Jack detection, multi-stream, front panel retasking
5. Audio shielding
6. Premium Japanese capacitors
7. Dedicated PCB layers
8. Requires front-panel HD audio module for full 7.1 output

—————————————————————————————————————————————————-

🔙 Rear I/O Ports

1. 1 x USB 3.2 Gen 2×2 Type-C®
2. 1 x USB 3.2 Gen 2 Type-A
3. 2 x USB 3.2 Gen 1 Type-A
4. 4 x USB 2.0 Type-A
5. 1 x DisplayPort
6. 1 x HDMI®
7. 1 x Wi-Fi antenna module
8. 1 x Realtek 2.5Gb Ethernet
9. 3 x Audio jacks
10. 1 x PS/2 combo port (Keyboard/Mouse)

—————————————————————————————————————————————————-

🧩 Internal I/O Connectors

1. Cooling:
2. 1 x CPU fan (4-pin)
3. 1 x CPU OPT fan
4. 1 x AIO pump header
5. 3 x Chassis fan headers
6. Power:
7. 1 x 24-pin main power
8. 1 x 8-pin +12V CPU
9. 1 x 4-pin +12V CPU
10. USB:
11. 1 x USB 3.2 Gen 2 (Type-C®)
12. 2 x USB 3.2 Gen 1 headers (4 ports)
13. 2 x USB 2.0 headers (4 ports)
14. Storage:
15. 3 x M.2 (Key M)
16. 4 x SATA
17. RGB Headers:
18. 3 x Gen 2 addressable
19. 2 x Aura RGB
20. Other Headers:
21. 1 x Clear CMOS
22. 1 x COM Port
23. 1 x Front Panel Audio (AAFP)
24. 1 x S/PDIF Out
25. 1 x SPI TPM (14-1 pin)
26. 1 x System Panel (20-5 pin)
27. 1 x Thunderbolt™ (USB4®) Header

—————————————————————————————————————————————————-

🛠️ Special Features

1. ASUS 5X Protection III:
2. DIGI+ VRM (with DrMOS)
3. LANGuard
4. Overvoltage Protection
5. SafeSlot Core+
6. Stainless Steel Back I/O
7. Q-Design Enhancements:
8. Q-DIMM, Q-LED Core, Q-Slot
9. Thermal Design:
10. Flexible M.2 heatsink
11. Large VRM heatsinks
12. DIY Enhancements:
13. ASUS EZ DIY tools
14. ProCool power connectors
15. RGB Ecosystem:
16. Aura Sync (Gen 2 ARGB & Aura RGB headers)

—————————————————————————————————————————————————-

💻 Software Features

1. Included Utilities:
2. Armoury Crate
3. Aura Sync RGB
4. Fan Xpert 4 (AI Cooling II)
5. AI Suite 3 (includes DIGI+ VRM, TurboV EVO, PC Cleaner)
6. ASUS CPU-Z
7. MyASUS
8. Power Saving Utility
9. Security & Trialware:
10. Norton 360 Deluxe (60-Day Trial)
11. WinRAR (Trial Version)
12. BIOS Tools:
13. ASUS UEFI BIOS (EZ & Advanced Modes)
14. EZ Flash 3
15. CrashFree BIOS 3

—————————————————————————————————————————————————-

📦 Accessories

1. 2 x SATA 6Gb/s Cables
2. 1 x ASUS Wi-Fi Antenna
3. 1 x I/O Shield
4. 1 x M.2 Rubber Package
5. 2 x M.2 SSD Screw Packages
6. 1 x User Guide
