| CPU |
AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors |
| Chipset |
AMD B850 Chipset |
| Memory |
4 x DIMM slots, max. 256GB, DDR5 / Supports up to 8000+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors, ECC and Non-ECC Un-buffered DIMM / Dual channel memory architecture / upports AMD Extended Profiles for Overclocking (EXPO™) / ASUS Enhanced Memory Profile (AEMP) / Adjustments will be made based on the specifications of mass-produced memory products available on the market. / Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/. / Non-ECC, un-buffered DDR5 memory supports On-Die ECC function. |
| Graphics |
1 x DisplayPort // 1 x HDMI™ port // Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications. // Supports max. 8K@30Hz as specified in DisplayPort 1.4. //Supports 4K@60Hz as specified in HDMI 2.1 |
| Expansion Slots |
AMD Ryzen™ 9000 & 7000 Series Desktop Processors : 1 x PCIe 5.0 x16 slot (supports x16 mode) // AMD Ryzen™ 8000 Series Desktop Processors : 1 x PCIe 4.0 x16 slot (supports x8/x4 mode) // AMD B850 Chipset : 1 x PCIe 4.0 x16 slot (supports x4 mode) / 2 x PCIe 4.0 x1 slots |
| Storage |
Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports : AMD Ryzen™ 9000 & 7000 Series Desktop Processors : M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode) / M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) /// AMD Ryzen™ 8000 Series Desktop Processors : M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) / M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4/x2 mode) /// AMD B850 Chipset : M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) : 4 x SATA 6Gb/s ports /// Specifications vary by CPU types. // AMD RAIDXpert2 Technology : Ryzen™ 9000 Series Processors: RAID 0/1/5/10 // Ryzen™ 8000 Series Processors: RAID 0/1 // Ryzen™ 7000 Series Processors: RAID 0/1/10 |
| Ethernet |
1 x Realtek 2.5Gb Ethernet / TUF LANGuard |
| Wireless & Bluetooth |
Wi-Fi 7 / 2×2 Wi-Fi 7 (802.11be) / Supports 2.4/5/6GHz frequency band // Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate // Bluetooth® v5.4 // Wi-Fi features may vary depending on the operating system. / For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E. / For Windows 10, please refer to the Wi-Fi chipset vendor’s website for details. / Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries. // The Bluetooth® version may vary, please refer to the Wi-Fi module manufacturer’s website for the latest specifications. |
| USB |
Rear USB (Total 10 ports) : 1 x USB 20Gbps port (1 x USB Type-C®) / 3 x USB 10Gbps ports (3 x Type-A) / 4 x USB 5Gbps ports (4 x Type-A) / 2 x USB 2.0 ports (2 x Type-A) /// Front USB (Total 7 ports) : 1 x USB 10Gbps connector (supports USB Type-C®) / 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports / 2 x USB 2.0 headers support 4 additional USB 2.0 ports // USB Type-C® power delivery output: max. 5V/3A. |
| Audio |
Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC : – Impedance sense for front and rear headphone outputs / – Internal audio Amplifier to enhance the highest quality sound for headphone and speakers / – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking / – High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) / – Supports up to 32-Bit/192 kHz playback* /// Audio Features : – Audio Shielding / – Premium audio capacitors / – Dedicated audio PCB layers / – Audio cover / – Unique de-pop circuit //Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio. |
| Back Panel I/O Ports |
1 x USB 20Gbps port (1 x USB Type-C®) / 3 x USB 10Gbps ports (3 x Type-A) / 4 x USB 5Gbps ports (4 x Type-A) / 2 x USB 2.0 ports (2 x Type-A) / 1 x DisplayPort / 1 x HDMI™ port / 1 x Wi-Fi module / 1 x Realtek 2.5Gb Ethernet port / 5 x Audio jacks / 1 x BIOS FlashBack™ button |
| Internal I/O Connectors |
Fan and Cooling Related : 1 x 4-pin CPU Fan header / 1 x 4-pin CPU OPT Fan header / 1 x 4-pin AIO Pump header / 4 x 4-pin Chassis Fan headers // Power Related : 1 x 24-pin Main Power connector / 2 x 8-pin +12V CPU Power connectors // Storage Related : 3 x M.2 slots (Key M) / 4 x SATA 6Gb/s ports // USB : 1 x USB 10Gbps connector (supports USB Type-C® ) / 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports / 2 x USB 2.0 headers support 4 additional USB 2.0 ports // Miscellaneous : 3 x Addressable Gen 2 headers / 1 x Clear CMOS header / 1 x Chassis Intrusion header / 1 x COM Port header / 1 x Front Panel Audio header (F_AUDIO) / 1 x 10-1 pin Front System Panel header / 1 x Thunderbolt™ (USB4®) header |
| Special Features |
ASUS TUF PROTECTION : – DIGI+ VRM (- Digital power design with DrMOS) / – ESD Guards / – TUF LANGuard / – Overvoltage protection / – SafeSlot / – Stainless-steel back I/O // ASUS Q-Design : – M.2 Q-Latch / – PCIe Slot Q-Release / – Q-Antenna / – Q-Dashboard / – Q-DIMM / – Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) / – Q-Slot // ASUS Thermal Solution : – M.2 heatsink / – VRM heatsink design // ASUS EZ DIY : – BIOS FlashBack™ button / – BIOS FlashBack™ LED / – ProCool / – Pre-mounted I/O shield / – SafeDIMM // Aura Sync : – Addressable Gen 2 headers |
| Software Features |
ASUS Exclusive Software : Armoury Crate : – Aura Creator / – Aura Sync / – Fan Xpert 4 / – Power Saving // ASUS DriverHub // ASUS GlideX // TurboV Core // TUF GAMING CPU-Z // DTS Audio Processing // Norton 360 for Gamers (60 Days Free Trial) // WinRAR (40 Days Free Trial) // UEFI BIOS // ASUS EZ DIY : – ASUS CrashFree BIOS 3 / – ASUS EZ Flash 3 / – ASUS UEFI BIOS EZ Mode / – ASUS MyHotkey |
| BIOS |
256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability |
WOL by PME, PXE |
| Accessories |
Cables : 2 x SATA 6Gb/s cables // Miscellaneous : 1 x ASUS WiFi Q-Antenna / 1 x TUF GAMING sticker / 2 x M.2 rubber packages // Documentation : 1 x Quick start guide |
| Operating System |
Windows 11 |
| Form Factor |
ATX Form Factor / 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
