| CPU |
LGA1851 socket: Support for Intel® Core™ Ultra Processors (Go to GIGABYTE’s website for the latest CPU support list.) / L3 cache varies with CPU |
| Chipset |
Intel® Z890 Express Chipset |
| Memory |
Support for DDR5 9200(O.C) / 9066(O.C) / 8933(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s memory modules. / 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory / Dual channel memory architecture / Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) / Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules / Support for Extreme Memory Profile (XMP) memory modules / Support CUDIMM memory module (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” for more information.) |
| Onboard Graphics |
Integrated Graphics Processor-Intel® HD Graphics support: -1 x USB4® USB Type-C® port, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840×2160@144 Hz / – 1 x DisplayPort, supporting a maximum resolution of 3840×2160@144 Hz |
| Audio |
Realtek® Audio CODEC / High Definition Audio / 2/4/5.1/7.1-channel |
| LAN |
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Expansion Slots |
CPU: – 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) / * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. /// Chipset: – 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1/2) |
| Storage Interface |
CPU: – 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 // PCIe 5.0 x4/x2 SSD support) (M2A_CPU) // – 1 x M.2 connector (Socket 3, M key, type 22110/2280 // PCIe 4.0 x4/x2 SSD support) (M2B_CPU) /// Chipset: – 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) / – 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB) / – 4 x SATA 6Gb/s connectors // RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices // RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
| USB |
CPU: – 1 x USB4® USB Type-C® port on the back panel /// Chipset: – 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header / – 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel / – 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) /// Chipset+2 USB 2.0 Hubs: – 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) |
| Internal I/O Connectors |
1 x 24-pin ATX main power connector / 2 x 8-pin ATX 12V power connectors / 1 x CPU fan header / 1 x CPU fan/water cooling pump header / 3 x system fan headers / 1 x system fan/water cooling pump header / 3 x addressable RGB Gen2 LED strip headers / 1 x RGB LED strip header / 4 x M.2 Socket 3 connectors / 4 x SATA 6Gb/s connectors / 1 x front panel header / 1 x front panel audio header / 1 x USB Type-C® header, with USB 3.2 Gen 2 support / 1 x USB 3.2 Gen 1 header / 2 x USB 2.0/1.1 headers / 2 x Thunderbolt™ add-in card connectors (For GIGABYTE Thunderbolt™ 5 add-in card only) / 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) / 1 x power button / 1 x Q-Flash Plus button / 1 x reset button / 1 x reset jumper / 1 x Clear CMOS jumper |
| Back Panel Connectors |
1 x USB4® USB Type-C® port (DisplayPort (Note)) / 2 x USB 3.2 Gen 2 Type-A ports (red) / 3 x USB 3.2 Gen 1 ports / 4 x USB 2.0/1.1 ports / 1 x DisplayPort (Note) / 2 x antenna connectors (2T2R) / 1 x RJ-45 port / 3 x audio jacks |
| I/O Controller |
iTE® I/O Controller Chip |
| H/W Monitoring |
Voltage detection / Temperature detection / Fan speed detection / Water cooling flow rate detection / Fan fail warning / Fan speed control |
| BIOS |
1 x 256 Mbit flash / Use of licensed AMI UEFI BIOS / PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features |
Support for GIGABYTE Control Center (GCC) / Support for Q-Flash / Support for Q-Flash Plus / Support for Smart Backup |
| Bundled Software |
Norton® Internet Security (OEM version) / LAN bandwidth management software |
| Operating System |
Support for Windows 11 64-bit |
| Form Factor |
ATX Form Factor; 30.5cm x 24.4cm |
