| CPU |
LGA1851 socket: Support for Intel® Core™ Ultra Processors / L3 cache varies with CPU |
| Chipset |
Intel® Z890 Express Chipset |
| Memory |
Support for DDR5 9066(O.C) / 8933(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s memory modules. /// 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity)of system memory // Dual channel memory architecture // Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) // Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules // Support for Extreme Memory Profile (XMP) memory modules // Support CUDIMM memory module |
| Onboard Graphics |
Integrated Graphics Processor-Intel® HD Graphics support: – 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz // * Support for HDMI 2.1 version and HDCP 2.3. / ** Support for native HDMI 2.1 TMDS compatible ports. / – 2 x DisplayPorts, supporting a maximum resolution of 4096×2304@60 Hz |
| Audio |
Realtek® Audio CODEC / High Definition Audio / 2/4/5.1/7.1-channel |
| LAN |
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Expansion Slots |
CPU: – 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) // Chipset: – 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) |
| Storage Interface |
CPU: – 1 x M.2 connector (Socket 3, M key, type 2580/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU) // Chipset: – 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)(M2Q_SB) / – 1 x M.2 connector (Socket 3, M key, type // 25110/22110/2580/2280 PCIe 4.0×4/x2 SSD support) (M2N_SB) / – 4 x SATA 6Gb/s connectors // RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices // RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
| USB |
Chipset: – 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header / – 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) / – 2 x USB 2.0/1.1 ports on the back panel // Chipset+2 USB 2.0 Hubs: – 4 x USB 2.0/1.1 ports available through the internal USB headers |
| Internal I/O Connectors |
1 x 24-pin ATX main power connector / 1 x 8-pin ATX 12V power connector / 1 x CPU fan header / 1 x CPU fan/water cooling pump header / 1 x system fan header / 1 x system fan/water cooling pump header / 2 x addressable RGB Gen2 LED strip headers / 1 x RGB LED strip header / 3 x M.2 Socket 3 connectors / 4 x SATA 6Gb/s connectors / 1 x front panel header / 1 x front panel audio header / 1 x USB Type-C® header, with USB 3.2 Gen 1 support / 1 x USB 3.2 Gen 1 header / 2 x USB 2.0/1.1 headers / 2 x Thunderbolt™ add-in card connectors / 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) / 1 x serial port header / 1 x Clear CMOS jumper |
| Back Panel Connectors |
1 x PS/2 keyboard/mouse port / 3 x USB 3.2 Gen 1 ports / 2 x USB 2.0/1.1 ports / 1 x HDMI port / 2 x DisplayPorts / 1 x RJ-45 port / 3 x audio jacks |
| I/O Controller |
iTE® I/O Controller Chip |
| H/W Monitoring |
Voltage detection / Temperature detection / Fan speed detection / Water cooling flow rate detection / Fan fail warning / Fan speed control |
| BIOS |
1 x 256 Mbit flash / Use of licensed AMI UEFI BIOS / PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features |
Support for GIGABYTE Control Center (GCC) / Support for Q-Flash / Support for Smart Backup |
| Bundled Software |
Norton® Internet Security (OEM version) / LAN bandwidth management software |
| Operating System |
Support for Windows 11 64-bit / Support for Windows 10 64-bit |
| Form Factor |
Micro ATX Form Factor; 24.4cm x 24.4cm |
