| Product Collection |
AMD Ryzen™ Processors |
| Processor Line |
AMD Ryzen™ 5 Desktop Processors 9000 |
| Total Cores |
6 |
| Total Threads |
12 |
| Max Turbo Frequency |
Up To 5.4GHz |
| OPERATING FREQUENCY |
3.9GHz |
| L1 Cache |
480 KB |
| L2 Cache |
6 MB |
| L3 Cache |
32 MB |
| PCI Express® Version |
PCIe® 5.0 |
| Max Memory Size |
192GB |
| Max of Memory Channels |
2 |
| System Memory Type |
DDR5 |
| Max Memory Speed |
2x1RDDR5-5600 // 2x2RDDR5-5600 // 4x1RDDR5-3600 // 4x2RDDR5-3600 |
| ECC Support |
Yes (Requires mobo support) |
| Thermal Solution (PIB) |
Not Included |
| Recommended Cooler |
Premium air cooler recommended for optimal performance |
| Supported Extensions |
AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
| Default TDP |
65W |
| Max Operating Temperature |
95°C |
| Multithreading (SMT) |
Yes |
| Unlocked for Overclocking |
Yes |
| Processor Technology for CPU Cores |
TSMC 4nm FinFET |
| Processor Technology for I/O Die |
TSMC 6nm FinFET |
| Package Die Count |
2 |
| CPU Socket |
AM5 |
| Socket Count |
1P |
| Instruction Set |
x86-64 |
| Graphics Model |
AMD Radeon™ Graphics |
| Graphics Core Count |
2 |
| Graphics Frequency |
2200 MHz |
| USB Type-C® DisplayPort™ Alternate Mode |
Yes |
| Supported Technologies |
AMD EXPO™ Technology AMD Ryzen™ Technologies |
